CNC880MCProduct image coming soon.
SZGH · SZGH-CNC880MC
SZGH CNC880MC CNC Milling Controller – Up to 6 Axes
CNC controller for milling machines and machining centers, up to 6 axes, with online PLC editing.
| Application | CNC milling machines and machining centers |
|---|---|
| Axes | Up to 6 |
| Interpolation cycle | 1 ms |
| Control accuracy | 1 µm / 0.1 µm selectable |
| I/O | 55 inputs / 42 outputs |
| PLC | Online editing |
| Communication | USB + pulse/analog servo interface |
Description
SZGH CNC880MC is a control unit for CNC milling machines, routers and machining centers. Suitable for new machines and retrofit projects.
